Generating an OpenAPI document and SDK from Spring Boot

You have a Spring Boot API and need to generate SDKs or API documentation for other teams. Rather than writing and maintaining separate OpenAPI specs, we will walk through how to generate them directly from your Spring Boot code, and then use them to create and customize an SDK.

We’ll work with real code you can run locally, building a simple bookstore API to demonstrate how to properly document API structures, including inheritance between models, endpoint definitions, response types, and error handling. The examples illustrate how Spring Boot annotations map to OpenAPI concepts, so you can see how your code translates into API specifications.

Example repository

The example below will guide you through the process of creating a Spring Boot project, adding the necessary dependencies, writing Spring Boot controllers with OpenAPI annotations, and generating an OpenAPI document from it. To skip this setup and follow along with our example, clone the example application (opens in a new tab).

Step 1: Set up a Spring Boot project

First, create a new Spring Boot project using Spring Initializr (opens in a new tab). Select the following options:

Project: Maven
Language: Java
Spring Boot: 2.7.x (or the latest stable version)
Project Metadata: Fill in as appropriate
Dependencies: Spring Web

Download the project and extract it to your preferred directory.

Step 2: Add OpenAPI dependencies

Open the pom.xml file and add the following dependency:

pom.xml

<dependency>
    <groupId>org.springdoc</groupId>
    <artifactId>springdoc-openapi-starter-webmvc-ui</artifactId>
    <version>2.1.0</version>
</dependency>

Step 3: Configure application properties

Open the src/main/resources/application.properties file and add the following configuration:

application.properties

# Specify the path of the OpenAPI documentation
springdoc.api-docs.path=/api-docs

springdoc.api-docs.version=OPENAPI_3_1

# Specify the path of the Swagger UI
springdoc.swagger-ui.path=/swagger-ui.html

These properties configure the application name that identifies your service, the endpoint where the OpenAPI document will be available (/api-docs), the version of the OpenAPI document to generate, and the URL path where you can access the Swagger UI documentation (/swagger-ui.html).

After starting your application, you can view the OpenAPI document at http://localhost:8080/api-docs and access the interactive Swagger UI at http://localhost:8080/swagger-ui.html.

Step 4: Write a Spring Boot application

All the code in this step can be found in our example application.

Open the src/main/java/com/bookstore/BookstoreApplication.java file in your text editor to see where to begin when adding OpenAPI annotations to your project.

The BookstoreApplication class is the entry point for the API. Similarly, we define the entry point to the OpenAPI document.

The @OpenAPIDefinition annotation populates the OpenAPI document with essential context for anyone who wants to use the API. This tells developers what the API does and how they can use it.

Use the title, version, and description fields to describe what the API does, its current state, and how it can be used.

The @Server annotation defines any available endpoints for the API. In the example, there are two options: A production server at https://api.bookstore.example.com that uses live data, and a localhost server at http://localhost:8080 for testing with sample data.

Open the Models.java file to see how you can use OpenAPI annotations to describe API data structures.

The @Schema annotation can be used at both the class and field levels to describe data structures in the OpenAPI documentation.

At the class level, @Schema describes what a Publication, Book, or Magazine represents in the API.

At the field level, fields like id and author are documented with a description of the field’s purpose and an example of the value that API users should provide or expect to receive.

The Publication class acts as the base schema in the OpenAPI specification.

By using @JsonTypeInfo and @JsonSubTypes, we tell OpenAPI that a Publication can be either a Book or Magazine. This polymorphism is reflected in the OpenAPI document as a oneOf schema, where each endpoint that works with publications can accept or return either type.

API clients will see that when working with publications, they need to include a type field set to either BOOK or MAGAZINE to properly identify the publication type.

The Order class uses the @Schema annotation to document the items field, which references the Publication schema.

This tells OpenAPI that Orders can contain an array of either books or magazines, using the polymorphic structure we defined earlier.

To document the available statuses of an Order, we annotate an enum with @Schema.

In the OpenAPI specification, this appears as a string field specifying a set of allowed values.

We annotate the ErrorResponse class with @Schema to describe any errors users might run into when using the API endpoints.

The next step is to define the API endpoints. We will go through the PublicationsController.java file to see how to map a Spring Boot controller to OpenAPI.

The @Tag annotation groups the operations in the controller under “Publications” in the OpenAPI document. Combined with @RequestMapping("/publications"), it tells API consumers that these endpoints handle publication-related operations.

On each method, you can use the @Operation and @ApiResponses annotations to document what the endpoint does and what responses to expect.

For example, getPublication has been annotated to show that it returns a publication successfully (200 status) or an error (404 status) if the publication isn’t found.

Use the @Parameter annotation to describe the requirements for input parameters.

BookstoreApplication.java

package com.bookstore;

import io.swagger.v3.oas.annotations.OpenAPIDefinition;
import io.swagger.v3.oas.annotations.info.Contact;
import io.swagger.v3.oas.annotations.info.Info;
import io.swagger.v3.oas.annotations.info.License;
import io.swagger.v3.oas.annotations.servers.Server;
import io.swagger.v3.oas.models.annotations.OpenAPI31;
import org.springframework.boot.SpringApplication;
import org.springframework.boot.autoconfigure.SpringBootApplication;

@SpringBootApplication
@OpenAPI31
@OpenAPIDefinition(
    info = @Info(
        title = "Book Store API",
        version = "1.0.0",
        description = "API for managing a book store inventory and orders",
        termsOfService = "https://bookstore.example.com/terms",
        contact = @Contact(
            name = "API Support",
            url = "https://bookstore.example.com/support",
            email = "support@bookstore.example.com"
        ),
        license = @License(
            name = "Apache 2.0",
            url = "https://www.apache.org/licenses/LICENSE-2.0.html"
        )
    ),
    servers = {
        @Server(url = "http://localhost:8080", description = "Local server"),
        @Server(url = "https://api.bookstore.example.com", description = "Production server")
    }
)
public class BookstoreApplication {
    public static void main(String[] args) {
        SpringApplication.run(BookstoreApplication.class, args);
    }
}

Step 5: View the generated OpenAPI document

Now that we’ve built the Spring Boot application, let’s generate and examine the OpenAPI document to understand how the Java code translates into API specifications.

First, install the necessary dependencies in the project and start the application with the following commands:

Terminal

./mvnw clean install
./mvnw spring-boot:run

Download the OpenAPI document while running the application:

Terminal

curl http://localhost:8080/api-docs.yaml -o openapi.yaml

This command saves the OpenAPI document as openapi.yaml in your current directory.

Let’s scroll through the generated OpenAPI document to see how our Spring Boot annotations were translated into an OpenAPI specification.

The OpenAPI document begins with version information.

This version is determined by the springdoc-openapi library we’re using. Simple, but important - it tells API consumers which OpenAPI spec version to expect.

Next comes the info object, which is generated from the @OpenAPIDefinition annotation.

This Java annotation transforms directly into the corresponding OpenAPI structure.

Notice how each field in the annotation maps directly to its counterpart in the OpenAPI document output. This one-to-one mapping makes it easy to understand how your code affects the final API documentation.

Server configurations defined with @Server annotations appear in the servers array.

These annotations generate the following OpenAPI structure.

One of the more complex aspects of the API is how polymorphic models are represented.

The Publication class has been translated into a schema that supports polymorphism through a discriminator.

A few key things to notice:

The @Schema annotations provide descriptions and examples
The @JsonTypeInfo annotation determines the discriminator property
The @JsonSubTypes annotation defines the possible concrete implementations

Finally, let’s examine how controller methods translate into API endpoints.

The @Operation annotation provides the summary and description.

Each @ApiResponse maps to an entry in the responses object.

The @Parameter annotation documents the path parameter.

openapi.yaml

openapi: 3.1.0
info:
  title: Book Store API
  description: API for managing a book store inventory and orders
  termsOfService: https://bookstore.example.com/terms
  contact:
    name: API Support
    url: https://bookstore.example.com/support
    email: support@bookstore.example.com
  license:
    name: Apache 2.0
    url: https://www.apache.org/licenses/LICENSE-2.0.html
  version: 1.0.0
servers:
- url: http://localhost:8080
  description: Local server
- url: https://api.bookstore.example.com
  description: Production server
tags:
- name: Orders
  description: Order management APIs
- name: Publications
  description: Publications management APIs
paths:
  /orders/{id}/status:
    put:
      tags:
      - Orders
      summary: Update order status
      description: Update the status of an existing order
      operationId: updateOrderStatus
      parameters:
      - name: id
        in: path
        description: ID of the order to update
        required: true
        schema:
          type: string
      - name: status
        in: query
        description: New status for the order
        required: true
        schema:
          type: string
          description: Possible statuses for an order
          enum:
          - PENDING
          - SHIPPED
          - DELIVERED
          - CANCELLED
      responses:
        "200":
          description: Order status updated successfully
          content:
            application/json:
              schema:
                $ref: "#/components/schemas/Order"
        "404":
          description: Order not found
          content:
            '*/*':
              schema:
                $ref: "#/components/schemas/ErrorResponse"
        "400":
          description: Invalid status
          content:
            '*/*':
              schema:
                $ref: "#/components/schemas/ErrorResponse"
  /publications:
    get:
      tags:
      - Publications
      summary: List all publications
      description: Get a list of all publications in the store
      operationId: listPublications
      responses:
        "200":
          description: Successful operation
          content:
            '*/*':
              schema:
                type: array
                items:
                  $ref: "#/components/schemas/PublicationListItem"
      x-speakeasy-retries:
        statusCodes:
        - 5XX
        backoff:
          initialInterval: 500
          maxInterval: 60000
          maxElapsedTime: 3600000
          exponent: 1.5
        strategy: backoff
        retryConnectionErrors: true
    post:
      tags:
      - Publications
      summary: Create a new publication
      description: Add a new publication to the store
      operationId: createPublication
      requestBody:
        content:
          application/json:
            schema:
              oneOf:
              - $ref: "#/components/schemas/Book"
              - $ref: "#/components/schemas/Magazine"
        required: true
      responses:
        "400":
          description: Invalid input
          content:
            '*/*':
              schema:
                $ref: "#/components/schemas/ErrorResponse"
        "200":
          description: Successful operation
          content:
            '*/*':
              schema:
                oneOf:
                - $ref: "#/components/schemas/Book"
                - $ref: "#/components/schemas/Magazine"
  /orders:
    get:
      tags:
      - Orders
      summary: List all orders
      description: Get a list of all orders in the system
      operationId: listOrders
      responses:
        "200":
          description: Successful operation
          content:
            '*/*':
              schema:
                type: array
                items:
                  $ref: "#/components/schemas/Order"
    post:
      tags:
      - Orders
      summary: Create a new order
      description: Create a new order for publications
      operationId: createOrder
      requestBody:
        content:
          application/json:
            schema:
              $ref: "#/components/schemas/Order"
        required: true
      responses:
        "400":
          description: Invalid input
          content:
            '*/*':
              schema:
                $ref: "#/components/schemas/ErrorResponse"
        "200":
          description: Order created successfully
          content:
            application/json:
              schema:
                $ref: "#/components/schemas/Order"
  /orders/{id}/cancel:
    post:
      tags:
      - Orders
      summary: Cancel an order
      description: Cancel an existing order
      operationId: cancelOrder
      parameters:
      - name: id
        in: path
        description: ID of the order to cancel
        required: true
        schema:
          type: string
      responses:
        "404":
          description: Order not found
          content:
            '*/*':
              schema:
                $ref: "#/components/schemas/ErrorResponse"
        "200":
          description: Order cancelled successfully
          content:
            '*/*':
              schema:
                $ref: "#/components/schemas/Order"
        "400":
          description: Order cannot be cancelled
          content:
            '*/*':
              schema:
                $ref: "#/components/schemas/ErrorResponse"
  /publications/{id}:
    get:
      tags:
      - Publications
      summary: Get a publication by ID
      description: Retrieves a publication's details by its unique identifier
      operationId: getPublication
      parameters:
      - name: id
        in: path
        description: ID of the publication to retrieve
        required: true
        schema:
          type: string
      responses:
        "404":
          description: Publication not found
          content:
            '*/*':
              schema:
                $ref: "#/components/schemas/ErrorResponse"
        "200":
          description: Successful operation
          content:
            '*/*':
              schema:
                oneOf:
                - $ref: "#/components/schemas/Book"
                - $ref: "#/components/schemas/Magazine"
  /orders/{id}:
    get:
      tags:
      - Orders
      summary: Get an order by ID
      description: Retrieves an order's details by its ID
      operationId: getOrder
      parameters:
      - name: id
        in: path
        description: ID of the order to retrieve
        required: true
        schema:
          type: string
      responses:
        "200":
          description: Successful operation
          content:
            '*/*':
              schema:
                $ref: "#/components/schemas/Order"
        "404":
          description: Order not found
          content:
            '*/*':
              schema:
                $ref: "#/components/schemas/ErrorResponse"
components:
  schemas:
    Book:
      allOf:
      - $ref: "#/components/schemas/Publication"
      - type: object
        properties:
          type:
            type: string
            default: Book
            description: Type of the publication
            enum:
            - Book
            example: Book
            readOnly: true
          author:
            type: string
            description: Author of the book
            example: Craig Walls
          isbn:
            type: string
            description: ISBN of the book
            example: 978-1617292545
      description: Represents a book in the store
      required:
      - type
    Magazine:
      allOf:
      - $ref: "#/components/schemas/Publication"
      - type: object
        properties:
          type:
            type: string
            default: Magazine
            description: Type of the publication
            enum:
            - Magazine
            example: Magazine
            readOnly: true
          issueNumber:
            type: integer
            format: int32
            description: Issue number of the magazine
            example: 42
          publisher:
            type: string
            description: Publisher of the magazine
            example: National Geographic Society
      description: Represents a magazine in the store
      required:
      - type
    Order:
      description: Represents an order for publications
      properties:
        id:
          type: string
          description: Unique identifier for the order
          example: ord-123456
        customerId:
          type: string
          description: Customer who placed the order
          example: cust-789012
        items:
          type: array
          description: List of items in the order
          items:
            $ref: "#/components/schemas/PublicationListItem"
          minItems: 1
        totalPrice:
          type: number
          format: float
          description: Total price of the order
          example: 89.97
        status:
          type: string
          description: Possible statuses for an order
          enum:
          - PENDING
          - SHIPPED
          - DELIVERED
          - CANCELLED
    Publication:
      description: Represents a publication in the store
      discriminator:
        propertyName: type
        mapping:
          Book: "#/components/schemas/Book"
          Magazine: "#/components/schemas/Magazine"
      properties:
        id:
          type: string
          description: Unique identifier of the publication
          example: 123e4567-e89b-12d3-a456-426614174000
        title:
          type: string
          description: Title of the publication
          example: Spring Boot in Action
        publishDate:
          type: string
          description: Publication date
          example: 2023-06-15
        price:
          type: number
          format: float
          description: Price in USD
          example: 39.99
        type:
          type: string
          description: Type of the publication
          enum:
          - Book
          - Magazine
          example: Book
    PublicationListItem:
      allOf:
      - $ref: "#/components/schemas/Publication"
      description: Represents an item in a list of publications
      discriminator:
        propertyName: type
        mapping:
          Book: "#/components/schemas/Book"
          Magazine: "#/components/schemas/Magazine"
      oneOf:
      - $ref: "#/components/schemas/Book"
      - $ref: "#/components/schemas/Magazine"
    ErrorResponse:
      description: Represents an error response
      properties:
        code:
          type: integer
          format: int32
          description: Error code
          example: 404
        message:
          type: string
          description: Error message
          example: Publication not found

Create an SDK from the OpenAPI document

Now that we have an OpenAPI document for the Spring Boot API, we can create an SDK using Speakeasy.

First, make sure you have Speakeasy installed:

Terminal

speakeasy --version

Now, generate a TypeScript SDK using the following command:

Terminal

speakeasy quickstart

Follow the onscreen prompts to provide the configuration details for the new SDK such as the name, schema location, and output path. Enter openapi.yaml when prompted for the OpenAPI document location and select your preferred language, for example, TypeScript, when prompted for which language you would like to generate.

After running this command, you’ll find the generated SDK code in the specified output directory. This SDK can be used by clients to interact with your Spring Boot API in a type-safe manner.

Customize the SDK

Let’s add retry logic to the SDK’s listPublications operation to handle network errors gracefully. We’ll do this using an OpenAPI extension that Speakeasy provides (opens in a new tab), x-speakeasy-retries.

Instead of modifying the OpenAPI document directly, we’ll add this extension to the Spring Boot controller and regenerate the OpenAPI document and SDK.

First, add these imports to src/main/java/com/bookstore/PublicationsController.java:

PublicationsController.java

import io.swagger.v3.oas.annotations.extensions.Extension;
import io.swagger.v3.oas.annotations.extensions.ExtensionProperty;

Then modify the listPublications operation to include the retry configuration:

PublicationsController.java

    @Operation(summary = "List all publications", description = "Get a list of all publications in the store", extensions = {
        @Extension(name = "x-speakeasy-retries", properties = {
            @ExtensionProperty(name = "strategy", value = "backoff"),
            @ExtensionProperty(name = "backoff", parseValue = true, value = "{\"initialInterval\":500,\"maxInterval\":60000,\"maxElapsedTime\":3600000,\"exponent\":1.5}"),
            @ExtensionProperty(name = "statusCodes", parseValue = true, value = "[\"5XX\"]"),
            @ExtensionProperty(name = "retryConnectionErrors", parseValue = true, value = "true")
        })
    })
    @ApiResponses(value = {
        @ApiResponse(responseCode = "200", description = "Successful operation",
                     content = @Content(array = @ArraySchema(schema = @Schema(implementation = PublicationListItem.class)))),
    })
    @GetMapping
    public ResponseEntity<List<Publication>> listPublications() {
        // This is a mock implementation. In a real application, you would fetch this from a database.
        List<Publication> publications = new ArrayList<>();
        publications.add(new Book(UUID.randomUUID().toString(), "Spring Boot in Action", "2015-10-01", 39.99f, "Craig Walls", "978-1617292545"));
        publications.add(new Magazine(UUID.randomUUID().toString(), "National Geographic", "2023-06-01", 9.99f, 6, "National Geographic Society"));
        return ResponseEntity.ok(publications);
    }

Now that we’ve added the x-speakeasy-retries extension to the listPublications operation, we can regenerate the OpenAPI document:

Terminal

curl http://localhost:8080/api-docs.yaml -o openapi.yaml

The OpenAPI document will include the retry configuration for the listPublications operation:

openapi.yaml

x-speakeasy-retries:
  statusCodes:
  - 5XX
  backoff:
    initialInterval: 500
    maxInterval: 60000
    maxElapsedTime: 3600000
    exponent: 1.5
  strategy: backoff
  retryConnectionErrors: true

Now we can use Speakeasy to recreate the SDK:

speakeasy quickstart

The created SDK will now include retry logic for the listPublications operation, automatically handling network errors and 5XX responses.

Issues and feedback

Need some assistance or have a suggestion? Reach out to our team at support@speakeasyapi.dev.
